IVGM sorozat
T-REX -50KHP3G01
50kW
Nagyfeszültség
4MPPTs
IP65
Three Phase
Termék bevezetése
The T-REX-50KHP3G01 50kW industrial and commercial inverter is a three-phase high-voltage inverter suitable for various industrial and commercial scenarios, including large factories, commercial complexes, industrial parks, etc. It has four built-in MPPT interfaces to maximize the capture of solar energy and improve system efficiency. This inverter supports multiple working modes, including grid-connected and off-grid, to adapt to different energy needs. Its intelligent cloud monitoring platform enables remote monitoring and management to ensure stable system operation. The IP65 protection level also ensures the reliability and durability of the inverter in harsh environments. Ensure stable and efficient solar energy conversion solutions under various energy needs and environmental conditions.
Termékelőnyök
• 230V/400V Three phase Pure sine wave inverter.
• Self - consumption and feed - in to the grid.
• Auto restart while AC is recovering.
• Programmable supply priority for battery or grid.
• Programmable multiple operation modes: On grid, off grid and UPS.
• With limit function, prevent excess power overflow to the grid.
• Supporting WIFI monitoring and Fsolar Smart Cloud Monitoring System.
• 8 - channel PV, 4 - channel MPPT, 1.3 times overconfiguration capacity.
• 2 independent battery inputs, effectively reducing inter - cluster circulation.
• Wide battery voltage input, each battery charge and discharge current up to 50A.
• Programmable generator port, support smart load and microinverter access.
• The off - grid switching time is less than 10ms to prevent important loads from losing power.
• Support multi Working mode, Time of use,Selling first, Zero export to load, Zero export to CT, Dispatch mode.
• The maximum support is 12 parallel machines.
• IP65 protection level.
• Self - consumption and feed - in to the grid.
• Auto restart while AC is recovering.
• Programmable supply priority for battery or grid.
• Programmable multiple operation modes: On grid, off grid and UPS.
• With limit function, prevent excess power overflow to the grid.
• Supporting WIFI monitoring and Fsolar Smart Cloud Monitoring System.
• 8 - channel PV, 4 - channel MPPT, 1.3 times overconfiguration capacity.
• 2 independent battery inputs, effectively reducing inter - cluster circulation.
• Wide battery voltage input, each battery charge and discharge current up to 50A.
• Programmable generator port, support smart load and microinverter access.
• The off - grid switching time is less than 10ms to prevent important loads from losing power.
• Support multi Working mode, Time of use,Selling first, Zero export to load, Zero export to CT, Dispatch mode.
• The maximum support is 12 parallel machines.
• IP65 protection level.
