IVGM Series

IVGM 25~50kW-P3G2

Name: IVGM25~50kW-P3G2 - Felicitysolar
SKU: NEW

25kW~50kW

High voltage

Hybrid

Three phase

IP65

Build-in WIFI for mobile monitoring

Product Introduction

This IP65-rated 50kW hybrid inverter features an LCD touchscreen for user-friendly parameter configuration. With multiple PV input channels, it optimizes energy yield, and up to 12 units can be connected in parallel to scale up system capacity. It also supports generator, smart load and microgrid connections. The dual independent battery inputs effectively reduce inter-cluster circulation. Ideal for small- to medium-scale commercial applications such as factories, supermarkets, hotels, and others.

Note: We also offer other inverters with various power ratings from 25kW to 50kW, allowing users to build solar energy systems that best fit their needs.

Product Advantages

• 230V/400V Three phase Pure sine wave inverter.
• Self-consumption and feed-in to the grid.
• Auto restart while AC is recovering.
• Programmable supply priority for battery or grid.
• Programmable multiple operation modes: On grid, OFF grid and UPS.
• With limit function, prevent excess power overflow to the grid.
• Supporting WlFl monitoring and Fsolar Smart Cloud Monitoring System.
• 2 independent battery inputs, effectively reducing inter-cluster circulation.
• Wide battery voltage input, each battery charge and discharge current up to 50A.
• Programmable generator port, support smart load and microinverter access.
• The off-grid switching time is less than 10ms to prevent important loads from losing power.
• Support multi Working Mode, Time Of Use,Selling First, Zero Export To Gridport,Zero Export To CT.
• IP65 protection level.

Upload one 50kW system to earn 50 points!

Join the 50kW Campaign！

A brand-new FLA48100 lithium battery, loads of coupons, plus an All-Inclusive Trip to Guangzhou are waiting for you!

360˚ Digital Surrounding View, Visualize Internal Structure

Rotate the mouse to see/scroll to zoom in and out.

Three-Phase Pure Sine Wave Output

Thanks to its phase-independent control of three-phase AC output, this inverter can provide stable three-phase power even when connected to a single-phase grid, making it ideal for areas where the grid is single-phase but the loads are three-phase.

Smart MPPT Technology with Multiple Inputs

Featuring a built-in solar charge controller and 1000V DC input, it maximizes solar module efficiency and allows the hybrid solar system to achieve superior energy conversion.

Ideal for Residential or Small to Medium Scale Commercial Use

This inverter supports up to 12 units in parallel, expanding total system power from 50kW to 600kW. It maximizes solar energy utilization and enables higher self-consumption. Most importantly, it helps users reduce electricity costs in the long term.

Smart Monitoring & Remote Management

In combination with FSOLAR IoT platform, system status, alarms and real-time data can be monitored via mobile or PC to ensure smart operation of the 3 phase solar inverter.

Dustproof and Waterproof Design

With IP65 protection level, it make the hybrid solar inverter function reliably under harsh environmental conditions.This ensures the hybrid solar system functions reliably under harsh environmental conditions.

Flexible Multi-Mode Operation

Being robust in on-grid, off-grid, and hybrid generator mode, the system is capable of being designed for various energy applications, thereby rendering the 3 phase solar inverter an all-purpose product for commercial and industrial use. It is an ideal central device for any premium hybrid solar system.

50K Series Model Comparison

Model	IVGM50KHP3G2	IVGM40KHP3G2	IVGM30KHP3G2	IVGM29K9HP3G2	IVGM25KHP3G2
Rated AC Input/Output Power	50kW	40kW	30kW	29.9kW	25kW
Max. Charging/Discharging Current	50A+50A
Number of MPPT Trackers/Number of Strings per MPPT	4/2		3/2		2/2
Battery Voltag Range	160-800Vd.c
Protection Level	IP65
Warranty (Years)	10

Application Scenarios Scenarios

Commercial Buildings

Provides stable power supply for malls, offices, and complexes, reducing electricity costs and enhancing energy independence.

Industrial Parks

Enables heavy equipment and manufacturing lines with less dependence on the grid and greater energy stability.

Agricultural Facilities

Enables consistent energy supply for greenhouses, irrigation, and cold storage to support modern agriculture.

Remote Areas

Enables stand-alone energy supply in regions which lack reliable access to the grid, improving the quality of life.

Application Solutions

Global Presence

Felicity Solar has established offices, warehouses, and service centers in more than 50 countries. This supports faster delivery, local after-sales services, and immediate technical support to customers globally.

Technological Innovation

With more than 170 patents in its staff and a strong R&D team, the company continuously upgrades its hybrid solar system and 3 phase solar inverter technology. MPPT control, IoT monitoring, and adaptable integration of systems are the result of continuous innovation.

Quality Assurance

The products are as per international standards such as CE, RoHS, and ISO9001. Every unit is thoroughly tested for quality to guarantee safety, effectiveness, and longer service life in any given use.

Professional Team

Backed by experienced engineers and renewable energy experts, Felicity Solar provides system design, installation guidance, and after-sales support to meet the needs of commercial and industrial clients.
